Basic features

External dimensions (mm)

W6320 * L11800 * H2480 (side 2260)

Internal dimensions (mm)

W6200 * L11600 * H2280 (side 2150)

Folded state (mm)

W2160*L11800*H2480

Total mass (kg)

5600

Frame structure

Top side beam

t2.5mmQ235B

Bottom side member

t23.0mmQ235B

End Side Beam

t2.5mmQ235B

Side wall frame

t1.7mmQ235B

secondary framework

t1.7mmQ235B

Hanging head

t4mmQ235B

Folding Hinge

13mm Galvanized Hinge

Integral frame protective coating

Electrostatic spray/straight white plastic powder

Top and bottom of middle cabinet

80*100*2.5 thick square tube

Side cabinet top and bottom

40*80*1.7 thick square tube

Box top

External top plate

t0.5 mm galvanized sheet

Internal suspended ceiling

T0.3mm831 type ceiling plate

Wall Panel

Intermediate roof insulation

t75mm glass wool/rock wool/EPS (side top 75 SPS color steel plate)

Side wall, front and rear wall panels

t 75mm SPS Color Steel Plate

Internal Partition

t 75mm SPS Color Steel Plate

Floor

Middle floor

Fireproof glass magnesium floor 15MM

Floor on both sides

Bamboo wood floor 18MM

Electrical System

   Electrical wiring, in strict accordance with the moisture-proof specification installation, all electrical products are required to meet the CE certification. Connect the circuit according to the circuit engineering specification, indoor: 3 LED lights, 3 five-hole single-open sockets, 3 ten-hole sockets, 3 air-conditioning sockets, and 1 20A leakage protector.

Voltage 220V,50HZ
